ZONESUN ZS-VTZL4A Vacuum Liquid Perfume Fragrance Filling Machine For Milk Eyewash Cosmetics

ZONESUN ZS-VTZL4A Vacuum Liquid Perfume Fragrance Filling Machine For Milk Eyewash Cosmetics

Size
/
  • One Year Warranty
  • User Manual
  • One-to-one Video Chat Support
  • Install & Debug Video
  • Custom Package Solution
  • Local Service Location （Romania /Serbia /Kazakhstan/Mexico/Indonesia）

Click Video Link For Video

The vacuum liquid filling machine can prevent the fragrance of liquid from spreading,this is especially good for perfume filling.It is full automatic and can work with automatic capping machine to realize automated production.Multiple filling nozzles can be customized according to production needs.

Parameter

Model:ZS-YTZL4A
Filling head:4 Head
Air pressure:0.5-0.8MPa
Liquid level accuracy:±1mm
Viscosity range:The maximum applicable viscosity is 20Cps (static viscosity)
Working Speed:20-40 Bottles/Minute
Bottle height:≤250mm
Bottle Opening Size:≤φ4.5mm-φ28mm
Adjustable liquid level (from the bottle mouth):15-50mm
Pumping rate:5.5L/S
Machine size:About 1500*1150*1530mm
Machine weight:About 278kg
Package size:About 1660*1310*1670mm
Package weight:About 339kg

ZS-VTZL4A Automatic Vacuum Liquid Filling MachineApplication of ZS-VTZL4A Automatic Vacuum Liquid Filling MachineDimension of ZS-VTZL4A Automatic Vacuum Liquid Filling MachineOperation of ZS-VTZL4A Automatic Vacuum Liquid Filling Machine

Simple operation panel,it can control the working parameter easily.It is no need to training operator.We can customize different kinds of languages according to operation needs.

Filling Nozzle of ZS-VTZL4A Automatic Vacuum Liquid Filling Machine
Use the vacuum constant liquid-level working principle,fill liquid accurately. If the liquid level is over the position that marked by red line,the machine will suck the extra liquid and make it back flow to the material container.The filling nozzle can be controlled separately.
Material Cylinder of ZS-VTZL4A Automatic Vacuum Liquid Filling Machine
Large material cylinder can be used to contain flowed back liquid.Ensures the filling accuracy.
Rotary Knob of ZS-VTZL4A Automatic Vacuum Liquid Filling Machine
The working height can be adjusted according to lifting structure,this makes sure the machine can work for different height of bottles.Improve working accuracy.
Electric Eye of ZS-VTZL4A Automatic Vacuum Liquid Filling Machine
The electric eye is designed to detecting passing by bottles,receive and send out working signal,prevent from missing bottles,and realize automated production.

ZS-VTZL4A Automatic Vacuum Liquid Filling MachineZS-VTZL4A Automatic Vacuum Liquid Filling Machine
