ZONESUN ZS-TB200 Automatic Glass Jam Jar Can Wine Bottle Labeler Conditioner Round Bottle Labeling Machine
Regular price
$4,099.00 USD
Regular price
Sale price
$4,099.00 USD
Save $-4,099 USD
/
- One Year Warranty
- User Manual
- One-to-one Video Chat Support
- Install & Debug Video
- Custom Package Solution
- Local Service Location （Romania /Serbia /Kazakhstan/Mexico/Indonesia）
This fully automatic bottle labeling machine is designed for single-side labeling. It accurately transfers bottles, separates labels, and applies them precisely. It can be equipped with a date printer for printing production dates. An ideal solution to improve labeling efficiency.
Parameter
- Machine Model: ZS-TB200
- Voltage: 110/220V 50-60HZ 1100W
- Label Length: 30-300 mm
- Label Width: 30-150 mm
- Suitable Bottle Diameter: φ20-120 mm
- Outside Diameter Of Standard Roll: φ280 mm
- Inside Diameter Of Standard Roll: φ76 mm
- Labeling Accuracy: ±1.0 mm
- Conveying Speed: 16m/min
- Marking Speed: 5 -19m/min
- Labeling Speed: 30-160 bottles/min
- Machine Weight: About 250 kg
- Packaging Size: About 2110*1000*1450 mm
- Package Weight: About 296 KG
Simple operation panel can be used to adjust and control working data, easy to operate and reduce working error greatly.
Electric eye can detect round bottles once they are transferred. It will not work unless the round bottle is detected. This prevents from missing bottles and wasting labels.
The label separating plate will separate stickers and stickers will be labeled by the labeling belt during transporting. The soft labeling belt can ensure there is no bubble under stickers, improves labeling quality.
Bottle separating device can separate passing through bottles, help to control the bottle distance, reduce labeling error.
The conveyor is used to transfer round bottles. The working speed is adjustable,operator can adjust the speed according to their need. The width of feeding inlet can be adjusted according to bottle diameter
