ZONESUN ZS-XG1870M Compact Desktop Plastic Spray Bottles Capping Machine For Energy Drinks Chocolate Jam Body Lotion Caps Screwing Machine
- One Year Warranty
- User Manual
- One-to-one Video Chat Support
- Install & Debug Video
- Custom Package Solution
- Local Service Location （Romania /Serbia /Kazakhstan/Mexico/Indonesia）
This capping machine is used to tighten screw-on caps like dropper bottles, spray bottles, compact machine body saves working space and production cost.This bottle capper is suitable for small scale production and can work with tabletop filling and labeling machine.
Parameter
- Machine model:ZS-XG1870M
- Working voltage:AC220V/110V 50-60HZ
- Bottle height:60-270mm
- Bottle caps diameter:18-70mm
- Conveyor length:1117mm
- Conveyor weight capacity:About 6kg
- Size of air compressor connector:OD 8mm
- Working speed:20-40 bottles/minute(depending on bottle and caps)
- Working pressure:0.4-0.6 MPa
- Package size:1130*660*1040mm
- Package weight:About 96kg
The PLC touch screen control panel shows working data more clearly, customizable interface simplies machine operation.Different kinds of operation language can be customized as needed.
Use four rubber wheels to tighten bottle caps, this kind of capping structure suitable for various kinds of caps like spray bottle, pump head bottle, dropper bottles. The working height can be adjusted according to bottle size.
The electric eye is used to detect passing by bottles and send signal to system to control the machine work automatically
The weight capacity of leather conveyor is not good as the chain conveyor, it is suitable for smaller bottles and small scale production.The guard rail can be adjusted according to bottle diameter, prevent bottles from falling down during conveying.
