ZS-XG440RS Automatic Servo Motor Pump Head Spray Caps Dropper Bottle Shampoo Body Lotion Liquid Soap Screw Capping Tightening Machine

Voltage
Machine Type
Price
Regular price $5,199.00 USD
Regular price Sale price $5,199.00 USD
Save $-5,199 USD
/
  • One Year Warranty
  • User Manual
  • One-to-one Video Chat Support
  • Install & Debug Video
  • Custom Package Solution
  • Local Service Location (Romania /Serbia /Kazakhstan/Mexico/Indonesia)

Servo Motor Capping Machine Video

Controlled by the servo motor , its precise and efficient torque control can ensure the accurate and consistent tightening of caps.It is suitable for the screw on caps like spray caps, dropper caps, pump head caps etc.It is the ideal choice for packaging shampoo, body lotion, cosmetic cream etc.

Parameter

  • Machine model:ZS-XG440RS
  • Power supply voltage:AC 110/220V 50-60HZ
  • Power:2KW
  • Suitable cover diameter:30-80mm(can be customized)
  • Working pressure:0.5-0.7MPa
  • Working speed:25-60 bottles/min
  • Machine size:About 200ox900X1600mm
  • Net weight:About 250kg

servo motor capping machine

application of servo motor capping machine

bottle capping machine

capping structure of servo motor capping machine

The capping structure is consist of 4 rubber wheels, this kind of capping method is suitable for various kinds of caps includes spray bottle caps, pump head bottle caps, dropper bottle caps etc.It widens application range and improves working efficiency.

cap guiding structure of servo motor capping machine

The bottle guiding structure can help to transport bottles.Some kinds of bottles are easier to fall down during transporting like falt bottles, this structure can ensure bottles can be transported smoothly, reduce production error.

Electric eye of servo motor capping machine

The electric eye can detect bottles according to light transmittance,and the sensitivity can be adjusted if you need to detect bottles which are in different kinds of colors.This ensures working accuracy.

Conveyor of servo motor capping machine

High quality conveyor belt can helpto transport bottle faster and moresmooth,improve working speed andreduce production error.

automatic capping machine
