ZS-YT4T-4PM Automatic 4 Heads Honey Jam Ketchup ChocolatePaste Bottle Filling Machine With Mixer Heater

SKU: ZS-YT4T-4PM
Paste Filling Machine WIth Mixer Heater
Hopper of Paste Filling Machine WIth Mixer Heater
Conveyor Belt of Paste Filling Machine WIth Mixer Heater
Check Valve of Paste Filling Machine WIth Mixer Heater
Paste Filling Machine WIth Mixer Heater
Paste Filling Machine WIth Mixer Heater

ZS-YT4T-4PM Automatic 4 Heads Honey Jam Ketchup ChocolatePaste Bottle Filling Machine With Mixer Heater

SKU: ZS-YT4T-4PM
Filling Range
Voltage
Regular price $7,193.99
/
Only 666 items in stock!
  • Multiple shipping method
  • Custom Service
  • Two Local Service Location
  • Secure payments

Click Video Link For Video

This machine is designed with mixing and heating function,and it can feed filling material automatically.This machine is good for filling pepper sauce,chocolate etc.Each nozzle can be controlled separately.It is widely used in food,beverage,daily chemical industries.

Parameter

Model:ZS-YT4T-4PM
Voltage:110/220v 50-60HZ 600W
Filling Range:5-100m/10-300ml/50-500mi/100-1000ml/500-3000m/1000-5000ml
Working Speed:20- 50bottles/Min(Based On Water)
Heating Temperature:About 0-300℃
Mixing Speed:About 1200r/min
Filling Accuracy:≤+1%
Air Pressure:0.5-0.7mpa
Conveyor Size:About 2000*100mm(l*w)
Size Of Filling Nozzle:φ10mm
Size Of Air Compressor Connector:φ10mm
Machine Weight:329kg
Machine Size:975*1020*2010mm
Package Weight:392kg
Package Size:1660*1130*2130mm

Paste Filling Machine With Mixer HeaterApplication of Paste Filling Machine With Mixer Heater

Machine Part of Paste Piston Pump Filling Machine With Mixer Heater

Operation Panle of Paste Piston Pump Filling Machine With Mixer Heater

Equipped with touch screen control panel,this makes working parameter visual and more convenient to operate.The operation language can be customized into different kinds of language according to your need,please contact us if you need this

Filling Nozzle of Paste Piston Pump Filling Machine With Mixer Heater

The high quality filling nozzle is with larger power when filling materials,this can improve filling efficiency.Each filling nozzle can be controlled separately.

Electric Eye of Paste Piston Pump Filling Machine With Mixer Heater

The electric eye can be used to detect bottles and control the machine to start or stop filling liquid into bottles.It realizes the automated production and can reduce production error.

Mixing Part of Paste Piston Pump Filling Machine With Mixer Heater

This machine is with mixing and heating function,the heating temperature and mixing speed can be adjusted according to the regulator.This is good for filling jam,face cream,chocolate etc.

Conveyor Belt of Paste Piston Pump Filling Machine With Mixer Heater

The chain conveyor belt is with weight capacity,good for transporting bottles stably.The length of conveyor belt can be customized according to production need.

Feeding Pump of Paste Piston Pump Filling Machine With Mixer Heater

Equipped with feeding pump,it can feed filling material automatically and no need to pour material into tank.This helps to save production labor and improve production efficiency.



Piston Pump Paste Filling MachinePiston Pump Paste Filling Machine
