Click For Video

This hot melt labeling machine is designed for attaching labels to square bottles, it has the hot melt glue supply system,which can ensure the accuracy and uniformity of gluing.The square bottles will rotate and labels will be attached smoothly. This machine is suitable for packaging engine oil, dish detergent.

Parameter

Machine model:ZS-GTB12S
Power supply:Three-phase 380V 50 Hz 8000W
Maximum labeling speed:1200-1400/h (production speed can be adjusted according to the actual situation)
Posting accuracy:±1mm
Label maximum width (height):180mm (customizable)
Label maximum length:750mm
Label maximum outer diameter:600 mm
Label minimum diameter:152mm
Glue type:hot melt adhesive, only apply glue on both ends of the label
Gluing temperature:120-160℃
Label type:OPP film label, paper-plastic composite film label, paper label
Labeling product type:Square bottle
Labeling machine host size:4650mm *1650mm *1650mm (L*W*H)
Machine weight Total Weight:About 1500 kg

detergent bottle hot melt glue labeling machine

application of bottle hot melt glue labeling machine

hot melt glue labeling machine

control panel of bottle hot melt glue labeling machine

Equipped with PLC touch screen control panel, the customized interface simplify machine debugging process. It is also more convenient to adjust working data according to working status in real time.

labeling structure of bottle hot melt glue labeling machine

Fixing mold is customized according to bottle size, bottles will be conveyed to the mold and be rotated to finish labeling work.This kind of labeling method has high working accuracy.

labeling structure of bottle hot melt glue labeling machine-1

Equipped with the hot melt glue supply system,this can apply glue on both ends of the label, ensure the labeling accuracy and consistency

bottle hot melt glue labeling machine
